Axygen Assay Microplate 96 Well V Bottom Clear 500 ul Case of 50 Plates

Axygen 96-Well Clear V-Bottom 500 µL Polypropylene Storage Assay Plate (P-96-450V-C) – Case of 50

The Axygen P-96-450V-C (by Corning) is a robust, automation-compatible 96-well microplate engineered for high-throughput screening, sample collection, and intermediate storage applications. Molded from premium, chemically inert virgin polypropylene, this plate features a maximum well capacity of 500 µL (with a standard 450 µL working volume) and an optimized V-bottom profile to elevate liquid recovery. Supplied non-sterile in a bulk case of 50 plates, this standard-profile matrix serves as a highly dependable platform for general assay preparation and automated liquid handling pathways.

Technical Performance & Design

• Precision V-Bottom Architecture: Outfitted with sharply tapered conical V-bottom wells that concentrate low-volume solutions at the absolute center of the well floor, minimizing costly sample dead volume during automated aspiration.
• Chemical & Cryogenic Resilience: Formed from clear virgin polypropylene that offers excellent resistance against aggressive solvents like DMSO, alcohols, and concentrated reagents while safely enduring ultra-low temperature freezing down to -80°C.
• Ultra-Flat Sealing Surface: Specially engineered with flat perimeter boundaries and raised well rims to promote tight, uniform adhesion when deployed with heat-sealing foils, adhesive films, or silicone compression mats.
• Standardized ANSI/SLAS Geometry: Adheres strictly to universal ANSI/SLAS 1-2004 microplate footprint standards, ensuring flawless interface alignment with microplate readers, automated liquid handlers, and standard centrifuge plate rotors.

Product Specifications

• Model Number / SKU: P-96-450V-C (Non-Sterile Configuration)
• Manufacturer: Axygen Scientific (A Corning Brand)
• Plate Array Format: Standard 96-Well Matrix (8 x 12 Grid Layout)
• Volumetric Capacity: 500 µL Total Volume per Well (Nominal working volume: 450 µL)
• Well Shape & Bottom: Round Wells with Conical V-Bottoms
• Material Composition: 100% High-Clarity Virgin Polypropylene (PP)
• Sterility Specification: Non-Sterile
• Packaging Configuration: 50 Plates per Case (Packaged as 10 plates per pack, 5 packs per case)
• Purity Verification: Certified RNase, DNase, and Pyrogen-free to maintain protocol stability

Key Benefits & Applications

• High-Volume Assay Preparation: Acts as an ideal master block for serial dilutions, compound mixing, and high-throughput sample partitioning prior to downstream analysis.
• Magnetic Bead Pellet Optimization: The steep conical profile ensures efficient magnetic bead containment and wash phases when tracking automated nucleic acid extractions on magnetic separation stations.
• Thermal Profiling Versatility: Built to withstand high-temperature thresholds, making the plate entirely autoclavable up to 121°C at 15 psi for sterile preparation protocols.
• Alphanumeric Matrix Indexing: Features high-visibility molded-in grid markers (A1 through H12) along with an indented corner notch to guarantee accurate sample identification and proper directional tracking during loading.

Axygen® is a registered trademark of Axygen, Inc. (a Corning company). The P-96-450V-C catalog number represents the bulk, non-sterile option. If your validation parameters require pre-sterilized arrays, matching pre-irradiated versions are assigned under part number P-96-450V-C-S.
