Savant Speed Vac Plus Concentrator SC210A

Savant SpeedVac Plus SC210A Vacuum Concentrator System (SC210A-3E210056-1B)

The Savant SpeedVac Plus SC210A Vacuum Concentrator (SC210A-3E210056-1B) is a benchtop centrifugal vacuum evaporation system designed for the rapid drying, concentration, and solvent recovery of biological and chemical samples. Utilizing a combination of centrifugal force, vacuum pressure, and controlled radiant heating, the SC210A prevents sample bumping and cross-contamination while evaporating water, organic solvents, and mild acids or bases. Featuring a chemical-resistant PTFE-coated aluminum chamber, a clear acrylic cover for continuous sample observation, and a microprocessor-driven control panel, this unit accommodates a wide variety of interchangeable rotor configurations for microcentrifuge tubes, test tubes, and microplates. Engineered for analytical laboratory workflows, the SC210A provides highly reproducible concentration cycles for genomics, proteomics, drug discovery, and environmental analysis.

Technical Performance & Structural Attributes

• PTFE-Coated Aluminum Chamber: Offers superior resistance against aggressive organic solvents, mild acids, and volatile reagents, extending overall chamber longevity.
• Controlled Radiant Chamber Heating: Variable temperature control enables efficient thermal transfer to accelerate evaporation without thermal degradation of delicate biomolecules.
• Centrifugal Bumping Prevention: High-speed internal rotor drive creates continuous centrifugal force, preventing solution boiling-over and cross-contamination during vacuum evacuation.
• Dual Automatic Bleed Valves: Integrated vacuum release valves automatically vent system pressure upon run completion to protect samples from sudden backflow.
• Transparent Cover Interface: Heavy-duty clear acrylic lid permits direct visual monitoring of sample evaporation progress without breaking vacuum seal.

Product Specifications

• Model / System Assembly: SC210A (Assembly Part Number: SC210A-3E210056-1B)
• Primary Manufacturer: Savant (Thermo Scientific / Thermo Fisher Scientific)
• Equipment Category: Centrifugal Vacuum Concentrator / SpeedVac System
• Chamber Material: Chemical-Resistant PTFE-Coated Cast Aluminum
• Temperature Control Range: Off, Low (approx. 35 degrees C), Medium (approx. 45 degrees C), High (approx. 65 degrees C)
• Vacuum Connection: Standard 1/2 in. ID Vacuum Hose Barb Fitting
• Rotor Drive Mechanism: Direct Magnetic Drive Motor System
• Rotor Capacity Options: Accommodates interchangeable rotors for 1.5/2.0 mL microcentrifuge tubes, 15/50 mL conical tubes, and 96-well microplates
• Operating Noise Level: Less than 55 dBA continuous operational sound level
• Dimensions (W x D x H): 15.0 in. x 18.0 in. x 12.0 in. (38.1 cm x 45.7 cm x 30.5 cm)
• Power Requirements: 115 V AC, 60 Hz, 6 Amps

Key Benefits & Applications

• Genomics & Proteomics Sample Prep: Rapidly concentrates DNA, RNA, oligonucleotides, and peptide fractions following extraction or chromatographic purification.
• HPLC & Mass Spectrometry Fraction Drying: Efficiently strips acetonitrile, methanol, and aqueous buffer mixtures from fractions prior to LC-MS analysis.
• Combinatorial & Environmental Analysis: Enables high-throughput concentration of environmental extracts, agricultural samples, and synthetic chemical compounds.

Used, tested to be in great working condition.
