Camfil Megalam Panel Filter H14 698 CFM 47 x 24 x 3 in.

Camfil 855027649 Megalam™ H14 HEPA Panel Filter (698 CFM, 47 x 24 x 3 in.)

The Camfil 855027649 Megalam™ is a premium H14 HEPA panel filter designed for terminal filtration in mission-critical cleanroom environments. Certified to provide a minimum efficiency of 99.995% at the Most Penetrating Particle Size (MPPS), this filter ensures an ultra-clean, particle-free environment compliant with ISO Class 5 standards and above. Featuring a nominal airflow of 698 CFM and measuring 47 x 24 x 3 inches, the unit utilizes Camfil’s advanced minipleat technology to deliver high-capacity filtration with exceptionally low pressure drop. Encased in a rigid anodized aluminum frame with high-integrity polyurethane sealant, the 855027649 is the industry standard for pharmaceutical, biotechnology, and semiconductor manufacturing facilities requiring stable, laminar airflow and long-term reliability.

Technical Performance and Design

• H14 Grade Absolute Filtration: Individually tested and certified according to EN 1822 to eliminate 99.995% of airborne particulates, providing the highest level of protection for aseptic and high-purity processes.

• Advanced Minipleat Media: The high-quality glass fiber media is precision-pleated to maximize surface area, ensuring a uniform face velocity and extending the operational lifespan of the filter.

• Energy-Efficient Operation: Optimized for a nominal airflow of 698 CFM, the low-resistance design reduces the load on FFU motors and HVAC systems, lowering total energy consumption.

• Leak-Free Construction: The media pack is fully encapsulated in a 3-inch deep anodized aluminum frame using high-purity polyurethane, ensuring a robust, airtight seal within the housing or ceiling grid.

Product Specifications

• Catalog Number: 855027649

• Filter Class: H14 (HEPA) / Filter Class K

• Dimensions: 47 x 24 x 3 inches (1194 x 610 x 76 mm)

• Nominal Airflow: 698 CFM

• Efficiency: 99.995% at MPPS

• Frame Material: Anodized Aluminum

• Media Type: Micro Glass Fiber (Minipleat)

Key Benefits & Applications

• Sterile Compounding & Filling: Ideal for pharmaceutical Grade A filling lines and sterile suites where laminar air is required to protect the product stream.

• Biomedical Research: Provides the high-efficiency filtration necessary for BSL-3 and BSL-4 exhaust and supply air systems.

• Microelectronics & Nanotechnology: Prevents yield-damaging nanoparticle contamination in cleanroom environments.

• Hospital Isolation Rooms: Delivers medical-grade HEPA filtration to maintain air quality and safety for healthcare workers and patients.
