KleanSep Ceramic Membrane Filter 0.45 um 8 Channel Pack of 3 Filters

KleanSep 14716138 Ceramic Membrane Filter – 0.45 µm, 8-Channel Tubular

The KleanSep 14716138 is an industrial-grade ceramic membrane designed for the most demanding liquid separation and clarification tasks. Featuring a multichannel tubular geometry with 8 distinct feed channels, this 0.45 µm microfiltration element is engineered to handle feedstreams with high turbidity, high oil concentrations, and abrasive particulates. The monolithic ceramic support is composed of high-purity alpha-alumina (Al2O3) or titania (TiO2), providing exceptional mechanical strength and a bursting pressure of up to 80 bar. The asymmetrical membrane structure ensures a high permeate flux and resistance to deep-pore fouling, facilitating easy restoration through hydraulic backpulsing or aggressive chemical CIP (Clean-in-Place) cycles. This filter is the premier choice for process industries where polymeric filters fail due to extreme temperatures, broad pH requirements (0–14), or exposure to harsh organic solvents.

Technical Performance and Design

• Multichannel Tubular Geometry: The 8-channel design (5 mm channel diameter) optimizes the surface-area-to-volume ratio while maintaining an open flow path that prevents clogging in high-solids applications.

• 0.45 µm Microfiltration: Precisely calibrated for the removal of bacteria, yeast, fine mineral particulates, and emulsified oil droplets from process fluids and wastewater.

• Extreme pH and Chemical Resilience: Operates seamlessly across a pH range of 0 to 14 and is unaffected by oxidizing agents, corrosive materials, and radiation, making it ideal for radioactive or highly acidic/alkaline waste streams.

• High-Temperature Stability: Capable of withstanding operating temperatures up to 150°C and standard steam sterilization at 121°C, ensuring compliance with sanitary and high-heat industrial protocols.

Product Specifications

• Catalog Number: 14716138

• Pore Size: 0.45 µm (Microfiltration)

• Format: 8-Channel (5 mm Hydraulic Diameter)

• Dimensions: ~25 mm External Diameter x 1178 mm Length

• Membrane Material: Ceramic Oxides (ZrO2, TiO2, or Al2O3)

• Max TransMembrane Pressure: 10 bar (145 psi)

Key Benefits & Applications

• Industrial Wastewater Recycling: Highly effective at treating oily water, removing heavy metals, and recycling liquid resources in the oil and gas or automotive industries.

• Food and Beverage: Used in the clarification of fruit juices, sugar syrups, and the microbiological stabilization of beverages where high-temperature sanitation is required.

• Chemical and Biotech Processing: Ideal for cell harvesting, enzyme recovery, and the filtration of bio-based formulations that are incompatible with standard plastic membranes.

• Long Service Life: The high abrasion resistance of the ceramic material ensures years of reliable performance, significantly reducing the total cost of ownership compared to frequent polymeric filter replacements.

All product names, logos, and brands are property of their respective owners.

Used. Great condition.
