Pall Capsule Filter KleenPak SUPOR EKV Membrane 0.2 um

Pall KA1EKVP6G KleenPak™ Capsule Filter (Supor® EKV, 0.2 µm, Gamma-Compatible)

The Pall KA1EKVP6G is a high-capacity, sterilizing-grade capsule filter designed for the rapid and secure filtration of biopharmaceutical fluids. Utilizing Pall’s proprietary Supor® EKV technology, this filter features an asymmetric double-layer PES membrane (0.2 µm rated) that provides exceptional flow rates and superior total throughput compared to standard symmetric membranes. The built-in 0.65 µm pre-filter layer protects the final 0.2 µm membrane from premature fouling, making it particularly effective for nutrient-rich cell culture media, complex buffers, and biological intermediates. As a "G" series model, this capsule is constructed from materials validated for gamma-irradiation, ensuring mechanical and chemical integrity when integrated into single-use manifolds.

Technical Performance and Design

• Asymmetric PES Membrane: The unique double-layer structure (0.65 µm over 0.2 µm) allows for high-capacity dirt loading and faster processing times, reducing the overall footprint required for large-volume filtration.

• Sterilizing-Grade Retention: Validated for the absolute removal of Brevundimonas diminuta (ATCC 19146) with a typical Titer Reduction Value (TRV) of >10⁷ per cm² of effective filtration area.

• Gamma-Compatible Housing: Manufactured from robust, high-purity polypropylene materials that maintain their structural integrity and low-extractable profile after exposure to standard gamma sterilization doses (up to 50 kGy).

• KleenPak™ Capsule Format: A self-contained, compact design that minimizes hold-up volume and eliminates the need for stainless steel housings, reducing cleaning validation requirements and capital expenditure.

Product Specifications

• Catalog Number: KA1EKVP6G

• Media Type: Supor® EKV (Asymmetric Polyethersulfone)

• Removal Rating: 0.2 µm (Sterilizing Grade)

• Configuration: KleenPak™ Size 1 Capsule

• Connections (P6): 1/2 inch (13 mm) Single Barb Hose Barb Inlet/Outlet

• Effective Filtration Area (EFA): 0.045 m² (approx. 480 cm²)

• Sterilization Compatibility: Gamma Irradiation Compatible; Autoclavable (125°C).

• Biological Safety: Meets USP Class VI Plastics tests; certified non-pyrogenic and non-fiber releasing.

Key Benefits & Applications

• Cell Culture Media Prep: Optimized for the rapid filtration of serum-free and serum-supplemented media where high flux is required to maintain nutrient stability.

• Intermediate Purification: Ideal for bioburden reduction or sterilization of protein-containing fractions after chromatography or ultrafiltration steps.

• Buffer Sterilization: Provides a fast and reliable method for sterilizing large-volume buffers used in downstream processing.

• Single-Use Systems: The gamma-compatible construction makes this an essential component for single-use assemblies used in aseptic filling and process fluid transfer.
