Repligen Pressure Transducer Polysulfone Pack of 3 Transducers

Repligen Single-Use Pressure Transducer, Polysulfone, Luer Lock (ACPM-799-01N) – Pack of 3 Transducers

The Repligen Single-Use Pressure Transducer (ACPM-799-01N) is a medical-grade, highly precise fluid pressure sensing component engineered for in-line monitoring across upstream and downstream bioprocessing applications. Manufactured from biocompatible, USP Class VI compliant polysulfone, this transducer provides robust chemical and thermal resistance during critical fluid transfer operations, including tangential flow filtration (TFF), hollow fiber cross-flow filtration, depth filtration, and chromatography purification. Designed with standard male/female Luer lock flow-through connections, it integrates seamlessly into flexible bioprocessing tubing sets, single-use assemblies, and automated pressure monitoring systems. Pre-calibrated and fully disposable, the ACPM-799-01N eliminates cross-contamination risks, cleaning validation overhead, and expensive sensor recalibration cycles. Supplied as a pack of 3 single-use pressure transducers, each unit features an integrated chip memory that communicates factory calibration data directly to compatible bioprocess controllers.

Technical Performance & Structural Attributes

• Single-Use Biocompatible Construction: Formulated from USP Class VI polysulfone to ensure low extractables/leachables and complete compatibility with biological buffers, cell culture media, and proteins.
• Pre-Calibrated Precision Sensing: Factory-calibrated with internal memory storage to enable immediate plug-and-play installation without manual zeroing or baseline adjustments.
• Sterilization Compatibility: Capable of withstanding gamma irradiation and autoclave cycles, maintaining structural and operational integrity in sterile bioprocessing lines.
• High-Accuracy Inline Flow Path: Low dead-volume, straight-through fluid path minimizes hold-up volume, shear stress, and flow restriction during sensitive biopharmaceutical processing.
• Standard Luer Connection Interface: Universal Luer lock fittings provide secure, leak-free integration with flexible tubing lines, sampling manifolds, and filter capsules.

Product Specifications

• Catalog / Part Number: ACPM-799-01N
• Primary Manufacturer: Repligen Corporation
• Pressure Measurement Range: -5.8 to 60 PSI (-0.4 to 4.1 bar)
• Body / Wetted Material: Polysulfone (PSU), USP Class VI Compliant
• Connection Format: Luer Lock (Flow-Through Design)
• Sensor Accuracy: ±0.05 PSI or ±1% of Reading (whichever is greater)
• Maximum Operating Temperature: Up to 50°C (122°F)
• Sterilization Integrity: Gamma Irradiated / Autoclavable
• Regulatory Compliance: USP Class VI, BSE/TSE Free, ISO 10993 Compliant
• Packaging Configuration: Pack of 3 Single-Use Transducers

Key Benefits & Applications

• Tangential Flow Filtration (TFF) & Microfiltration: Continuously monitors feed, retentate, and filtrate pressures to calculate Transmembrane Pressure (TMP) during cell harvesting and concentration.
• Chromatography & Column Protection: Prevents over-pressurization of delicate chromatography columns and delicate membrane absorbers during biopurification steps.
• Sterile Single-Use Assemblies: Ideal for integration into disposable bioprocess fluid pathways, bioreactor sampling lines, and bulk fill-finish lines.

All product names, logos, and brands are property of their respective owners. Repligen is a registered trademark of Repligen Corporation.
