Repligen MidiKros Hollow Fiber Filter 20 cm Length 0.2 um PES 1 mm FLL X FLL

Repligen MidiKros Hollow Fiber Filter, 20 cm Length, 0.2 µm mPES, 1.0 mm ID, FLL x FLL (P-D02-E20U-10-N)

The Repligen MidiKros Hollow Fiber Filter (P-D02-E20U-10-N) is a high-performance single-use tangential flow filtration (TFF) module engineered for pilot-scale, benchtop, and clinical bioprocessing applications. Featuring a 0.2 µm sterilizing-grade pore size microfiltration membrane composed of modified Polyethersulfone (mPES), this filter delivers exceptional flux rates, low protein binding, and high volumetric throughput during bio-burden reduction, cell clarification, and particle separation workflows. Designed with a 20 cm active path length and a wide 1.0 mm lumen inner diameter (ID) fiber geometry, the module reduces fluid shear stress and accommodates higher viscosity fluids or higher cell density feeds. Encapsulated in a clear, biocompatible polysulfone housing with standard Female Luer Lock (FLL) process and permeate port connections, the MidiKros module seamlessly integrates into automated or manual TFF assemblies, enabling linear scale-up to larger bioprocess-scale filtration systems while eliminating cleaning validation and cross-contamination risks.

Technical Performance & Structural Attributes

• Advanced mPES Membrane Chemistry: Hydrophilized modified Polyethersulfone provides minimal non-specific binding, excellent chemical tolerance across a broad pH range, and reduced membrane fouling during complex biological separations.
• Wide 1.0 mm Lumen Diameter: High-clearance 1.0 mm inner diameter fibers reduce cross-flow shear stress on delicate cellular structures while preventing channel clogging from high-solids feeds.
• Single-Use Encapsulated Design: Factory-assembled and potted in a USP Class VI housing, eliminating cartridge installation steps, system cleaning validation, and water-for-injection (WFI) pre-flushing requirements.
• Standardized Luer Lock Interface: Features Female Luer Lock (FLL) fittings on both process feed/retentate flow paths and side permeate ports for fast, leak-free connection to flexible tubing circuits and sampling manifolds.
• Linear Bioprocess Scalability: Shares identical fluid channel height and membrane properties with larger KrosFlo and MaxiKros hollow fiber modules to ensure predictable performance during scale-up.

Product Specifications

• Catalog / Part Number: P-D02-E20U-10-N
• Primary Manufacturer: Repligen Corporation
• Filter Module Series: MidiKros Hollow Fiber Module
• Membrane Material: Modified Polyethersulfone (mPES)
• Pore Size Rating: 0.2 µm (Microfiltration / Bio-burden Reduction)
• Fiber Inner Diameter (ID): 1.0 mm
• Active Module Path Length: 20 cm
• Feed / Retentate Connections: Female Luer Lock (FLL)
• Permeate Port Connections: Female Luer Lock (FLL)
• Housing Material: Polysulfone (PSU), USP Class VI Compliant
• Regulatory Compliance: USP Class VI, ISO 10993, Gamma Irradiated / Autoclavable, Non-Pyrogenic

Key Benefits & Applications

• Sterilizing Microfiltration & Bio-Burden Reduction: Provides effective removal of bacteria, cellular fragments, and particulate matter from culture broths and buffer solutions.
• Cell Clarification & Bioreactor Harvesting: Ideal for continuous or batch harvesting of mammalian cells (CHO, HEK293) and plant cell cultures under low-shear fluidic conditions.
• Viral Vector & Nanoparticle Concentration: Gently concentrates large biological complexes, adenovirus/AAV vectors, liposomes, and cellular exosomes without altering particle integrity.
